Moderate Complexity – 5000 Series

Moderate Complexity – 5000 Series

The CoxGomyl 5000 Series machines are designed for use on buildings of moderate complexity. When developing concepts using the 5000 Series range, the designers at CoxGomyl draw from a collection of standard features and options, to achieve a solution perfectly tailored to the architectural and functional requirements of the building.

The selection keys beside each product are designed to help in the identification of the most suitable product type at a high level, based on machine outreach as criteria.

The 5000 Series of products are divided into three main groups; the selection key is based on machine outreach, operational options and movements

E-Type – The Economical Short Reach Choice

E-Type – The Economical Short Reach Choice

The E-Type machines are made from standardised components and are designed to be an economical choice, with reach of up to 8 metres. With a well thought out design, E-Type machines are low maintenance and safe to operate.

F-Type – The Flexible Choice

F-Type – The Flexible Choice

Often referred to as ‘crane type’ BMU, the F-Type is used when the reach or suspended load is increased beyond the capabilities of the E-Type. Due to their larger mass, F-Type machines will generally operate on twin steel rails.

There are two main derivatives in the range:

F1 –BMU Features
  • The frame housing the hoist is part of the main structural frame of the machine.
  • Can be provided with telescoping jib and a full range of cradles.Selected if:
  • There is minimal space at the back for the counterweight
  • Required outreach generally in the 5-15m range
  • Building height is up to 450m.
F2 – BMU Features
  • The frame housing the hoist is part of the main structural frame of the machine.
  • Can be provided with telescoping jib and a full range of cradles.Selected if:
  • There is minimal space at the back for the counterweight
  • Required outreach generally in the 5-15m range
  • Building height is up to 450m.
G-Type – The Grand Choice

G-Type – The Grand Choice

Sharing many of the features of the F-Type, the G-Type was designed for larger buildings or where a larger reach is required. Typically, G-Type machines have a reach of 25 to 50 metres, a wide range of cradles and approaching systems, as well as different climbing options for moving the BMU on pitched surfaces.

G2 – BMU Features
  • The frame housing the hoist is part of the main structural frame of the machine.
  • Can be provided with telescoping jib and a full range of cradles.Selected if:
  • There is minimal space at the back for the counterweight
  • Required outreach generally in the 5-15m range
  • Building height up to 500m.
